4001 Series 4 Roller Pump - Silvercast with 12 volt DC Monitor

Mfg Part #:
4001XL-AE2H
SKU:
620-4001XL-AEH PUMP/MTR

$643.20
Hypro roller pumps are designed for agricultural and industrial spraying and transfer of a variety of fluids. These include insecticides, herbicides, emulsives, aromatic solvents, liquid fertilizers and many other liquids. The economical rotary-action roller principle requires no check valves while providing positive displacement characteristics with less friction and lower starting torque than other pumps. The 4000 series, 4-roller, 12-volt pump achieves up to 10.4 gpm, and 100 psi depending on the model. ÊThe series includes models 4001N-EH, 4001XL-EH, 4101N-EH, 4101XL-EH, 4001N-E2H, 4001XL-E2H, 4101N-E2H, 4101XL-E2H.

Features:

  • 4001XL-H pump coupled to E2H 12 volt DC motor
  • Max flow: 9.9 gpm
  • Max pressure: 60 psi
  • Max rpm: 1600
  • Port sizes: 3/4" FNPT
  • Pump shaft rotation: CW
  • Housing: Silvercast
  • Rotor: Silvercast
  • Roller material: Super rollers standard, Poly and Teflon available
  • Roller quantity: 4
  • Shaft seals: Viton standard, Buna available
  • Shaft: 1/2" hollow stainless steel
  • Max fluid temperature: 140¡F
  • Weight: 21 lbs
